Midea M-Thermal Arctic Mono R290 MHC-V6WD2N7-E30 Heat Pump
Midea M-Thermal Arctic Mono R290 MHC-V6WD2N7-E30 Heat Pump
Midea M-Thermal Arctic Mono R290 MHC-V6WD2N7-E30 Heat Pump
Midea M-Thermal Arctic Mono R290 MHC-V6WD2N7-E30 Heat Pump

Midea M-Thermal Arctic Mono R290 MHC-V6WD2N7-Е30 Heat Pump

In stock
3,999.00 €
  • Cooling
    6.80 kW
  • Heating
    6.20 kW
  • SEER 7°C
    5.32 A
  • SCOP 35°C
    4.89 A+++
  • Noise
    46 dB

+35932 390 107
or
SEND INQUIRY

Technical specifications for Midea M-Thermal Arctic R290 Mono MHC-V6WD2N7-Е30 Heat Pump
Model nameMHC-V6WD2N7-Е30
Power SupplyV/Ph/Hz220-240/1/50
Heating A7W35CapacitykW6.20
Rated inputkW1.27
COP4.90
Heating A7W45CapacitykW6.40
Rated inputkW1.68
COP3.80
Heating A7W55CapacitykW6.20
Rated inputkW2.00
COP3.10
Heating A2W35CapacitykW5.60
Rated inputkW1.44
COP3.90
Heating A2W45CapacitykW5.80
Rated inputkW1.87
COP3.10
Heating A2W55CapacitykW5.80
Rated inputkW2.19
COP2.65
Heating A-7W35CapacitykW5.90
Rated inputkW2.00
COP2.95
Heating A-7W45CapacitykW5.50
Rated inputkW2.20
COP2.50
Heating A-7W55CapacitykW5.20
Rated inputkW2.42
COP2.15
Cooling A35W18CapacitykW6.50
Rated inputkW1.28
EER5.10
Cooling A35W7CapacitykW6.80
Rated inputkW2.19
EER3.10
Seasonal space heating energy efficiency classWater outlet at 35⁰CA+++
Water outlet at 55⁰CA++
SCOPWarmer climate35⁰C6.14
55⁰C4.55
Average climate35⁰C4.89
55⁰C3.82
Colder climate35⁰C4.24
55⁰C3.38
SEERWater outletW7°C5.32
W18°C6.65
ErP sound power leveldB58
Sound Power LevelHeating (A7W35)dB58
Heating (max)dB60
Heating (silence mode 1)dB56
Heating (silence mode 2)dB53
Cooling (A35W18)dB58
Cooling (max)dB60
Cooling (silence mode 1)dB56
Cooling (silence mode 2)dB53
Sound pressure level (1m)Heating (A7W35)dB(A)46
Heating (max)dB(A)48
Heating (silence mode 1)dB(A)44
Heating (silence mode 2)dB(A)42
Cooling (A35W18)dB(A)46
Cooling (max)dB(A)48
Cooling (silence mode 1)dB(A)43
Cooling (silence mode 2)dB(A)40
Sound pressure level (2m)Heating (A7W35)dB(A)42
Heating (max)dB(A)44
Heating (silence mode 1)dB(A)40
Heating (silence mode 2)dB(A)37
Cooling (A35W18)dB(A)42
Cooling (max)dB(A)44
Cooling (silence mode 1)dB(A)40
Cooling (silence mode 2)dB(A)37
Water flow rangem3/hmm0.40 - 1.25
CompressorTypeTwin rotary
Outdoor fanMotor typeDC fan
Number of fans1
Air side heat exchangerFinned tube heat exchanger
Refrigerant

R290 (700g)

Unit dimension (W×H×D)mm1299 × 717 × 426
Packing dimension (W×H×D)mm1375 × 885 × 475
Net weightkg90
Gross weightkg110
Water side heat exchangerPlate heat exchanger
Water side Connection dimensionG1"BSP
Water pumpMax. pump headm9
Expansion vessel (Primary circuit)Nominal volumeL8
Max. working pressureBar8
Safety valveMPa0.3
Flow switchm3/h0.36
Outdoor air temperature rangeCooling°C-5 ~ 46
Heating°C-25 ~ 35
DHW°C-25 ~ 46
Water setting temperature rangeCooling°C5 ~ 30
Heating°C12 ~ 75
DHW°C10 ~ 70


Note:

  1. The above data test reference standard EN14511; EN14825; EN50564;EN 12102; (EU) No:811
Manufacturer Midea
Type Heat pumps
Technology Inverter
Series M-Thermal Arctic
Outdoor Unit MHC-V6WD2N7-E30
Power supply (V/ø/Hz) 230 / 1 / 50
Cooling Capacity (kW) 6.80
Heating Capacity (kW) 6.20
Power Input Cooling/Heating (kW) 2.19 / 1.27
EER (Energy Efficiency in Cooling) 3.10
COP (Energy Efficiency in Heating) 4.90
SEER (Seasonal Cooling Efficiency) 5.32
SCOP (Seasonal Heating Efficiency) 4.89
Energy Efficiency Class (Cooling) A
Energy Efficiency Class (Heating) A+++
Sound Power Outdoor Unit - Cooling/Heating dB(A) 58 / 58
Dimensions - Outdoor Unit WxHxD (mm) 1375 × 885 × 475
Weight - Outdoor Unit (kg) 90
Operation Range - Cooling (°C) -5 ~ 46
Operation Range - Heating (°C) -25 ~ 35
Built-in water tank (L) No
Refrigerant (type) R290
Warranty 3 years
