The new R32 refrigerant significantly improves the technical characteristics of the air conditioning system and provides higher energy efficiency. R32 is the most balanced CFC ever created and used, while not adversely affecting the ozone layer and protecting the environment.
When Turbo mode is activated, the compressor starts running at maximum speed to ensure the desired temperature faster. When the desired room temperature is reached, the compressor will run in normal mode.
This mode provides maximum comfort and peace of mind throughout the night for healthier sleep. When cooling the room with the "Sleep" mode activated, the preset temperature rises by 1 degree, one hour after the air conditioner is started, after which it remains fixed. When heating the room with the "Sleep" mode activated, the temperature drops by 1 degree, one hour after starting the air conditioner, after which it remains fixed.
After loss of power supply voltage, the air conditioning system will automatically switch on with the last set mode and settings when the power is restored.
Programable timer for automatic ON or OFF switching of the air conditioner at a pre-selected time of the day.
Thanks to the Wi-Fi module, you will be able to control the air conditioning system via your smartphone or tablet from anywhere in the world.
|Type||Wall type air conditioners|
|Power supply (V/ø/Hz)||230 / 1 / 50|
|Capacity (BTU)||9 000 BTU|
|Cooling Capacity (kW)||2.64 (0.90 - 3.40)|
|Heating Capacity (kW)||2.93 (0.82 - 3.37)|
|Power Input Cooling/Heating (kW)||0.73 / 0.73|
|SEER (Seasonal Cooling Efficiency)||6.30|
|SCOP (Seasonal Heating Efficiency)||4.00|
|Energy Efficiency Class (Cooling)||A++|
|Energy Efficiency Class (Heating)||A+|
|Current for Cooling / Heating (A)||3.18（0.4 - 5.4) / 3.18（0.5 - 5.2)|
|Sound Pressure Indoor Unit - Cooling dB(A)||38.5 / 32 / 25|
|Sound Pressure Indoor Unit - Heating dB(A)||38.5 / 32 / 25|
|Sound Pressure Outdoor Unit - Cooling/Heating dB(A)||55.5 / 55.5|
|Sound Power Indoor Unit - Cooling/Heating dB(A)||54 / 54|
|Sound Power Outdoor Unit - Cooling/Heating dB(A)||62 / 62|
|Air Flow Indoor / Outdoor Unit - Cooling (m3/h)||466 / 360 / 325 / 1750|
|Dimensions - Indoor Unit WxHxD (mm)||805 x 285 x 194|
|Dimensions - Outdoor Unit WxHxD (mm)||720 x 495 x 270|
|Weight - Indoor Unit (kg)||7.6|
|Weight - Outdoor Unit (kg)||23.2|
|Piping Connections - Liquid/Gas (mm)||φ 6.35 / φ 9.52|
|Maximum Pipe Lenght (m)||25|
|Maximum Height Difference (m)||10|
|Operation Range - Cooling (°C)||-15 ~ 50|
|Operation Range - Heating (°C)||-15 ~ 30|
