In the 8°C heating mode, this constant temperature is maintained, thus protecting the home from excessive cooling in winter or freezing of pipes and houseplants. The regime is especially suitable in the long absence of the occupants of the home.
Bio filter (HEPA)
The bio filter consists of a special biological enzyme and a HEPA filter. The HEPA filter captures very small dust particles, bacteria, fungi and microbes. The biological enzyme kills bacteria by breaking down their cell wall, thus eliminating the problem of re-contamination.
El. heaters for work at low temperatures
At the bottom of the outdoor unit is an electric heater, which prevents condensation from freezing at negative temperatures. A second heater is mounted on the compressor, which makes it easier to start the system on cold winter days.
Golden Fin coating is more resistant to oxidation and corrosion than ordinary Blue Fin coating. Golden Fin effectively prevents the growth and spread of bacteria and improves resistance to corrosive elements.
|Type||Wall type air conditioners|
|Series||Xtreme Heat Nordic|
|Power supply (V/ø/Hz)||230 / 1 / 50|
|Capacity (BTU)||9 000 BTU|
|Cooling Capacity (kW)||2.64 (0.82 ~ 3.66)|
|Heating Capacity (kW)||2.93 (0.79 ~ 4.40)|
|Power Input Cooling/Heating (kW)||0.57 (0.06 ~ 1.20) / 0.62 (0.75 ~ 1.40)|
|SEER (Seasonal Cooling Efficiency)||8.50|
|SCOP (Seasonal Heating Efficiency)||4.60|
|Energy Efficiency Class (Cooling)||A+++|
|Energy Efficiency Class (Heating)||A++|
|Current for Cooling / Heating (A)||2.50 (0.3 ~ 5.2) / 2.70 (0.32 ~ 6.08)|
|Sound Pressure Indoor Unit - Cooling dB(A)||36.5 / 28 / 24 / 23|
|Sound Pressure Indoor Unit - Heating dB(A)||36.5 / 28 / 24 / 23|
|Sound Pressure Outdoor Unit - Cooling/Heating dB(A)||56 / 56|
|Sound Power Indoor Unit - Cooling/Heating dB(A)||53 / 53|
|Sound Power Outdoor Unit - Cooling/Heating dB(A)||55 / 55|
|Air Flow Indoor / Outdoor Unit - Cooling (m3/h)||510 / 360 / 300 / 2100|
|Dimensions - Indoor Unit WxHxD (mm)||835 х 295 х 208|
|Dimensions - Outdoor Unit WxHxD (mm)||765 х 555 х 303|
|Weight - Indoor Unit (kg)||8.7|
|Weight - Outdoor Unit (kg)||29.5|
|Piping Connections - Liquid/Gas (mm)||φ 6.35 / φ 9.52|
|Maximum Pipe Lenght (m)||25|
|Maximum Height Difference (m)||10|
|Operation Range - Cooling (°C)||-15 ~ 50|
|Operation Range - Heating (°C)||-25 ~ 24|
